A gusset plate is a thin metal object, typically made from steel, used to affix structural members to one another or to connect beams and girders to columns. These components are a crucial part of the structure — they transmit the internal forces from the connected members.
Uses of a gusset plate
- Used in steel structures to connect beams and columns to one another, or to connect them with truss members.
- Supports the entire structure by distributing the complete load.
- Widely used in bridges and many other structures.
Considerations while designing gusset plates
- The shape, size, and thickness of the plate should depend on the direction of the members connecting at the joint.
- Higher loads on the structural members require a thicker plate; lower loads allow a thinner plate.
- The shape can be rectangular, square, or triangular — or customised to the requirement.
- The primary purpose of the plate is to withstand the shear and direct bending stresses meeting at the same section.
- The plate size is set to meet the pitch and edge-distance specifications of the bolts connecting the members at the joint.
Material used for gusset plates
The material depends on the application and the structural loads. Gusset plates are commonly made from galvanised steel for its anti-corrosive properties. For smaller applications they are sometimes made from aluminium or copper, which also gives a clean, shiny finish.
Applications of gusset plates
- Connections in steel building construction.
- Truss connections.
- Large mechanical equipment.
- Vehicle and pedestrian bridges.
Designing gusset-plate connections to code
Designing and checking gusset plates by hand is time-intensive, and the buckling and Whitmore-section checks are an easy place to slip. Modelling the plate on its real geometry and letting the software run every weld, bolt and plate check to code removes that risk.
The tool for this
Code-check any steel connection to AISC & Eurocode.
Model welded, bolted and moment connections on the real geometry with CBFEM — clear pass/fail results and a full report in minutes.
FAQs
What is a gusset plate?
A gusset plate is a thin metal object, typically made of steel, used to affix structural members to one another or connect beams and girders to columns.
What is the primary purpose of a gusset plate?
To withstand shear and direct bending stresses at the section where members meet, distributing the complete load.
What materials are used to make gusset plates?
Commonly galvanised steel for its anti-corrosive properties, but also aluminium or copper for specific applications.
Where are gusset plates used?
In steel building connections, truss connections, large mechanical equipment, and vehicle or pedestrian bridges.
How is the thickness of a gusset plate determined?
It depends on the load — higher structural loads require thicker plates, lower loads allow thinner plates.
What shapes do gusset plates come in?
Rectangular, square, triangular, or customised based on the joint requirements.
